• FRAME
Extruded aluminum 1.8 mm nominal wall thickness & 75 mm (3”) depth with 1” extruded aluminum flange.
• Optional: extruded aluminum Frame Channel Type
Model: K3-SCRF.
• BLADES
Extruded aluminum 1.4 mm nominal wall thickness.
• BLADE CENTERS
60 mm (2-1/2”) maximum centers at head and sills.
Corrosion resistant steel fasteners used at assembly.
• WIRE MESH
- Galvanized bird screen (standard)
- Aluminum bird screen
- Stainless steel bird screen
- Galvanized insect screen
- Aluminum insect screen
- Stainless steel insect screen
• FINISH
- Mill Finish (standard)
- Anodize
- All RAL colors
• SIZES
Minimum width: 8”
Minimum height: 8”
Maximum single section:
Width 144” x Height 92”
Width 92” x Height 144”
• Multiple section: Unlimited
Maximum single section area: 13248 in2
N.B: 6 mm clearance is deducted from your order size.
For more information please consult our engineers.
